Procedure

  1. Connect Pin-1 (Input & Output) of ICBase-1 to Input-15.
  2. Connect Pin-1 (Input & Output) of ICBase-1 to Output-15.
  3. Connect Pin-1 (Input & Output) of ICBase-2 to Pin-2 (Input & Output) of ICBase-1.
  4. Connect VCC Port to Pin-20 (Input & Output) of ICBase-1.
  5. Connect VCC Port to Pin-20 (Input & Output) of ICBase-3.
  6. Connect Pin-7 (Input & Output) of ICBase-3 to GND Port.
  7. Connect Pin-7 (Input & Output) of ICBase-3 to Pin-7 (Input & Output) of ICBase-2.
  8. Connect Pin-7 (Input & Output) of ICBase-3 to Pin-7 (Input & Output) of ICBase-1.
  9. Connect Input-15 to Pin-5 (Input & Output) of ICBase-2.
  10. Connect Pin-3 (Input & Output) of ICBase-1 to Input-14.
  11. Connect Pin-16 (Input & Output) of ICBase-2 to Input-14.
  12. Connect Pin-2 (Input & Output) of ICBase-1 to Input-15.
  13. Connect Pin-5 (Input & Output) of ICBase-1 to Input-13.
