NAND as OR

Parv Pahuja
Parv Pahuja
• Created on Apr 25, 2026 • 0 • 0 • 0
Edit Circuit Copy Circuit Try Yourself
NAND as OR
100%

Procedure

  1. Add IC 74LS00 into ICBase-1 (74LS00).
  2. Connect GND Port to Pin-7 (Ground) of ICBase-1 (74LS00).
  3. Connect VCC Port to Pin-20 (VCC) of ICBase-1 (74LS00).
  4. Connect Input-15 to Pin-1 (Input) of ICBase-1 (74LS00).
  5. Connect Pin-2 (Input) of ICBase-1 (74LS00) to Input-15.
  6. Connect Input-14 to Pin-4 (Input) of ICBase-1 (74LS00).
  7. Connect Pin-5 (Input) of ICBase-1 (74LS00) to Input-14.
  8. Connect Pin-15 (Input) of ICBase-1 (74LS00) to Pin-3 (Output) of ICBase-1 (74LS00).
  9. Connect Pin-16 (Input) of ICBase-1 (74LS00) to Pin-6 (Output) of ICBase-1 (74LS00).
  10. Connect Output-0 to Pin-14 (Output) of ICBase-1 (74LS00).
