Untitled circuit

GOWTHU HARANI
GOWTHU HARANI
• Created on Feb 19, 2026 • 0 • 0 • 1
Edit Circuit Copy Circuit Try Yourself
Untitled circuit
100%

Integrated Circuits Used

74LS08

Procedure

  1. Add IC 74LS08 into ICBase-3 (74LS08).
  2. Connect Pin-7 (Ground) of ICBase-3 (74LS08) to GND Port.
  3. Connect Pin-20 (VCC) of ICBase-3 (74LS08) to VCC Port.
  4. Connect Pin-1 (Input) of ICBase-3 (74LS08) to Input-3.
  5. Connect Input-12 to Pin-7 (Ground) of ICBase-2 (74LS08).
  6. Connect Pin-10 (Input & Output) of ICBase-1 to Output-14.
  7. Connect Input-10 to Pin-4 (Input) of ICBase-2 (74LS08).
  8. Connect Pin-17 (Input & Output) of ICBase-1 to Input-8.
  9. Connect Input-9 to Pin-17 (Input & Output) of ICBase-1.
  10. Connect Pin-5 (Input) of ICBase-3 (74LS08) to Input-8.
  11. Add IC 74LS08 into ICBase-2 (74LS08).
