full adder and full subtractor
100%

Integrated Circuits Used

74LS00

Procedure

  1. Connect VCC Port to Pin-20 (VCC) of ICBase-1 (74LS00).
  2. Connect GND Port to Pin-7 (Ground) of ICBase-1 (74LS00).
  3. Connect Input-0 to Pin-1 (Input) of ICBase-1 (74LS00).
  4. Connect Input-1 to Pin-2 (Input) of ICBase-1 (74LS00).
  5. Add IC 74LS00 into ICBase-1 (74LS00).
