New Circuit

Niaz Ali
Niaz Ali
• Created on Oct 3, 2025 • 0 • 0 • 1
Edit Circuit Copy Circuit Try Yourself
New Circuit
100%

Integrated Circuits Used

74LS03

Procedure

  1. Add IC 74LS03 into ICBase-1 (74LS03).
  2. Connect Input-13 to Pin-1 (Input) of ICBase-1 (74LS03).
  3. Connect Input-12 to Pin-2 (Input) of ICBase-1 (74LS03).
  4. Connect Input-11 to Pin-4 (Input) of ICBase-1 (74LS03).
  5. Connect Input-10 to Pin-5 (Input) of ICBase-1 (74LS03).
  6. Connect GND Port to Pin-7 (Ground) of ICBase-1 (74LS03).
  7. Connect Pin-6 (Output) of ICBase-1 (74LS03) to Output-6.
  8. Connect Pin-3 (Output) of ICBase-1 (74LS03) to Output-7.
  9. Connect Pin-17 (Output) of ICBase-1 (74LS03) to Output-5.
  10. Connect Pin-14 (Output) of ICBase-1 (74LS03) to Output-4.
  11. Connect Input-9 to Pin-15 (Input) of ICBase-1 (74LS03).
  12. Connect Input-8 to Pin-18 (Input) of ICBase-1 (74LS03).
  13. Connect Input-7 to Pin-19 (Input) of ICBase-1 (74LS03).
  14. Connect Input-5 to Pin-16 (Input) of ICBase-1 (74LS03).
  15. Connect VCC Port to Pin-20 (VCC) of ICBase-1 (74LS03).
