RIPPPLE COUNTER
100%

Integrated Circuits Used

74LS90

Description

DONE BY BHUVENESH

Procedure

  1. Add IC 74LS90 into ICBase-1 (74LS90).
  2. Connect VCC Port to Pin-5 (VCC) of ICBase-1 (74LS90).
  3. Connect Pin-16 (Ground) of ICBase-1 (74LS90) to GND Port.
  4. Connect Pin-18 (Output) of ICBase-1 (74LS90) to Output-0.
  5. Connect Seven segment display 1 to Pin-18 (Output) of ICBase-1 (74LS90).
  6. Connect Output-1 to Pin-15 (Output) of ICBase-1 (74LS90).
  7. Connect Output-3 to Pin-17 (Output) of ICBase-1 (74LS90).
  8. Connect Seven segment display 1 to Pin-17 (Output) of ICBase-1 (74LS90).
  9. Connect Output-2 to Pin-14 (Output) of ICBase-1 (74LS90).
  10. Connect Pin-14 (Output) of ICBase-1 (74LS90) to Seven segment display 1.
  11. Connect GND Port to Pin-2 (Input) of ICBase-1 (74LS90).
  12. Connect GND Port to Pin-6 (Input) of ICBase-1 (74LS90).
  13. Connect GND Port to Pin-7 (Input) of ICBase-1 (74LS90).
  14. Connect GND Port to Pin-3 (Input) of ICBase-1 (74LS90).
  15. Connect Pin-1 (Input) of ICBase-1 (74LS90) to Pin-18 (Output) of ICBase-1 (74LS90).
  16. Connect Clock port of 1Hz frequency to Pin-20 (Input) of ICBase-1 (74LS90).
  17. Connect Pin-15 (Output) of ICBase-1 (74LS90) to Seven segment display 1.
  18. Connect GND Port to ICBase-1 (74LS90).
  19. Connect Output-0 to ICBase-1 (74LS90).
  20. Connect Output-1 to ICBase-1 (74LS90).
  21. Connect Seven segment display 1 to ICBase-1 (74LS90).
  22. Connect Seven segment display 1 to ICBase-1 (74LS90).
  23. Connect VCC Port to ICBase-1 (74LS90).
  24. Connect Seven segment display 1 to ICBase-1 (74LS90).
